Led Txhaj Module
Led txhaj tshuaj module feem ntau yog siv rau cov ntawv me, thiab nws yog nrog lub teeb ci siab 1.5watts, Nws tuaj yeem yog qhov kev xaiv zoo tshaj plaws rau sab nraum zoov kos npe. Lub LED Module yog txhaj tshuaj uas lav cov dej tsis zoo, noo noo-pov thawj thiab plua plav pov thawj.
Parameter
|
Qauv: |
4015 coj txhaj tshuaj module |
|
Chip: |
SMD 2835 |
|
Loj: |
40 * 15mm |
|
Xim: |
Dawb, Liab, Xiav, Ntsuab, Daj, Paj yeeb, Ntshav |
|
Lub zog (W): |
1.5 watts |
|
Voltage: |
DC 12 V |
|
Xim kub: |
3000-20000K |
|
Lumen / module: |
150ML |
|
Ua haujlwm kub: |
-25 degree ~ 60 degree |
|
IP Tus Nqi: |
IP65 |
|
Beam Angle: |
160 degree kaum sab xis |
|
Ntawv pov thawj: |
CE thiab ROHS |
|
Lub Sijhawm Lub Neej: |
20, 000 teev |
|
Warranty: |
3 Xyoo |
|
Dimmable: |
Tsis muaj |
|
Qhov hnyav (KG): |
0.005kg |
|
Khoom siv: |
Aluminium PCB ntxiv rau PVC |
|
Lub teb chaws ntawm keeb kwm: |
Tuam Tshoj |
|
Kev siv: |
Channel Tsab ntawv.light Box.backlight, signage |
Feature
|
· Kev sib txuas yog tsim nyog. LED modules tsis txhawb kev sib txuas sib txuas. Ib qho kev sib txuas serial ua rau lub zog poob |
|
· Kev siv hluav taws xob tsawg: tib lub ci ci, kev siv hluav taws xob tsawg thiab hluav taws xob ntau dua li cov khoom zoo sib xws; |
|
· Cov txheej txheem zoo PVC txhaj tshuaj molding txheej txheem nrog 160 lub kaum sab xis optical lens, zoo nkauj tsos, zoo tshav kub dissipation |
|
· Txais cov tub ntxhais tooj liab dawb huv, muaj kev nyab xeeb dua thiab txhim khu kev qha |
|
· Lub 20pcs modules nyob rau hauv ib txoj hlua, thiab ib qho module tuaj yeem txiav |
|
· Super siab brightness nrog tus nqi zoo tshaj, zoo lav ntau tshaj 3years |
|
· DC12V tsis tshua muaj hluav taws xob tawm tswv yim, nyab xeeb thiab txhim khu kev qha, tsis muaj dej tsis zoo IP65 |
Daim ntawv thov
Cov khoom no feem ntau yog siv rau Billboard, Signage thiab illuminated advertising, Raws li lub Backlighting ntawm channel ntawv thiab lub teeb lub thawv
Pob
Txhua 20 pcs rau ib txoj hlua, txhua 10 txoj hlua inan anti-static hnab, 4000 pcs rau ib lub thawv ntawv. Thawv loj: 58 * 30 * 30 cm.
Net Nyhav: 5 g / pcs; 100 g / hnab; 20kg / thawv.
peb lub tuam txhab tshwj xeeb hauv kev tsim thiab xa tawm ntawm cov coj modules tau 10 xyoo, Muab tus kheej customization, pwm ntiag tug thiab lwm yam txheej txheem, Peb ua raws li cov neeg siv khoom-oriented zoo tom qab-muag kev pab cuam.
LED Module FAQ
1. Ntev npaum li cas tom qab them nyiaj yuav khoom xa tuaj?
-3-5 hnub rau cov khoom tsis tu ncua, 7-10 hnub rau cov khoom siv
2.Dab tsi yog qhov kev lees paub zoo?
- Peb lav qhov no rau 3 xyoos
3.Yuav ua li cas xa cov khoom rau kuv qhov chaw nyob?
- Cov khoom me me tuaj yeem xa los ntawm kev nthuav qhia, cov khoom loj tuaj yeem xa los ntawm hiav txwv, huab cua thiab kev tsheb ciav hlau, thiab lwm yam. Thov tso koj cov lus txiav txim thiab chaw nyob rau peb los xyuas koj.
